55 inch miniled high brightness tft-lcd display
| Resolution | 3840×2160 |
| The whole machine can achieve brightness | 4000nits（Typ.)(without UV)，3200nits（Typ.)(with UV) |
| Refresh rate | 60HZ |
| LCD screen contrast ratio | 1200:1 |
| Display color | 1.07G |
| Transmissivity | 7.6 (Typ.) % |
| Pixel pitch | 315(H) ×315(V)um |
| LCD screen with viewing angle | ≥178°（CR>10） |
| Brightness viewing angle | Horizontal ≥ 68 °, vertical ≥ 62 ° |
| Response time | 8ms |
| Dimming control mode | Local Diming(192 partitions) |
| Color gamut | 68%（Min.），72%（Typ.） NTSC 1931 |
| Color correction of production line | auto white balance |
| Power consumption | 315w（logic） |
| Surface Treatment | AGLR（QWP-POL） |
| Weight | 19kg（Theoretical value) |
| Special usage environment | 0℃-40℃（No direct sunlight），0℃-30℃（direct sunlight），10%-80%RH |
