480kw ocpp protocol compatible EV super charger charging stack

Technical Parameters


Model: GEVD-480F

Output power: Using 20KW charging module, the maximum output of total p。wer from single machine is 240KW, and use in N+1 parallel mode is available.

Using 30KW charging module, the maximum output of total power from single machine is 360KW,。nd use in N+1 parallel m。de is available.

Using 40KW charging module, the maximum output of total power from single machine is 480KW,。nd use in N+1 parallel mode is available


Input voltage: AC400V +/- 20%

AC frequency range: 50/60HZ±10%

Output voltage: DC200-750V/DC200-1000V

Output ripple coefficient:《0.1%

Communication interface: Ethernet and 2G/3G/4G are optional

Safety regulation protection: Insulation resistance 罢王10Mn, withstand voltage 2500VAC, protecti。n level IP54

Safety and compliance:IEC 61851-1; IEC 61851-23; IEC 61851-21-2; ISO 15118 Plug&Charge

Warranty:24 months, warranty extension possible

Current stabilizati。n accuracy:ζ±1%

Harmonic distortion (THDi):》5%

Output current:CCS2: Standard: 200A; Optional 300A (Nominal), 400A (Peak)

CHAdeMo: 125A or 200A

Voltage stabilization accuracy: ::s;;o.5%

Reliability: MTBF注100,000 hours

Pr。tection functions:O叫,ercurrent, overvoltage, undervoltage, integrated surge protection, PME (UK)

Operating environment: altitl』deζ2000m (apply derating when exceeding this altitude), temperature -40-70°C, humidity below 95%

.
