AUO 24 inch TFT-LCD display panel for laptop and monitor M240HTN01.2

Panel brand AUO panel model M240HTN01.2

Panel size 24.0 inches Panel type a-Si TFT-LCD, LCD module

Resolution 1920 (RGB) × 1080, FHD, 91PPI pixel layout RGB vertical stripe

Display area 531.36 (W) × 298.89 (H) mm Appearance size 556 (W) × 323.2 (H) × 12 (D) mm

Visible size 535.4 (W) × 303.0 (H) mm Surface treatment matte (Haze 25%), Hard coating (3H)

Brightness (cd/m ²) 250 (Typ.) Contrast 1000:1 (Typ.) [Transmission]

Best angle 6 O'clock optical mode TN, normally white display, transmissive IPS hard screen series: AAS, ADS, AHVA, FFS, HFS, HIS, IPS, New Mode 2, PLS, SFT, Vistarich<br/>VA soft screen series: ASV, FSA, HVA, MVA, PVA, SVA, UV²A, VA

Viewing angle 85/85/80/80 (Typ.) (CR ≥ 10) Left/Right/Up/Down response speed 3.5/1.5 (Typ.) (Tr/Td) ms

Color quantity 16.7M, 72% NTSC backlight type 9S4P WLED, 30K hours, no driver

Screen weight 1.89 ± 0.08Kgs suitable for computer monitors

Refresh frequency 75Hz [Screen Library copyright reserved, plagiarism strictly prohibited]<br/>120Hz (60HZ input): Built in MEMC circuit<br/>120Hz+120Hz: 120Hz panel+120Hz backlight<br/>240Hz (60HZ input): Built in MEMC circuit touch function no touch

Signal system LVDS (2 ch, 8-bit), terminal, 30 pins

Supply voltage 5.0V (Typ.)

Maximum rated storage temperature: -20~60 ° C Operating temperature: 0~50 ° C
